Multi-core wire stripping and terminal crimping machine
This Multi-core wire stripping and terminal crimping machine is highly integrated, synchronously completing the peeling and crimping processes, significantly enhancing efficiency, accuracy and consistency, and reducing core wire damage. Specifically designed for multi-core wires, the Multi-core wire stripping and terminal crimping machine not only can automatically organize the core wires and precisely crimp, but this Multi-core wire stripping and terminal crimping machine also ensures connection reliability. At the same time, it saves space and manpower.
Product Specification
|
Model |
GVY-1800 |
|
Motor |
One set of Mitsubishi servo motor from Japan and three sets of stepper motors. |
|
Pneumatic element |
Yadea valve + SMC solenoid valve |
|
Lead screw |
2 sets of TBI |
|
Guide rail |
5 sets of Taiwan Shangyin |
|
Belt |
Gates of America |
|
Bearing |
The NSK brand of Japan |
|
Blade |
Made of imported alloy steel, it is processed by slow wire cutting and precisely ground, ensuring long-lasting durability. |
|
Power supply |
AV220V single-phase 50/60 HZ |
|
Installation weight |
About 200 kilograms |
|
Boundary dimension |
L810 x W520 x H1370 |
|
Operating pressure |
0.5-0.7Mpa(5-7KG/m3) |
|
Main function |
Cut the multi-core wires evenly, remove the insulation, and make the ends. Divide the wires, trim them evenly, strip the insulation, and make the ends. |
|
Processing range |
AGG28-AWG16#(Special wires are subject to actual conditions.) |
|
Peeling length |
0-5mm |
|
Cutting accuracy |
±0.01mm |
|
Maximum machining Length |
The length of the core wire section is the shortest at 20mm, and there is no limit to the maximum length. |
|
Terminal machine Pressing force |
2T Ultra Quiet Variable Frequency Terminal Machine |
|
Matching mold |
Assembly line machine molds, professional molds |
|
Waste product disposal |
Sorting (with a cutting device installed at the head); the good products and defective products can be placed in separate boxes. |
|
Detecting system |
Sorting (with a cutting device installed at the head); It can be optionally equipped (applicable to both domestic and imported systems) to separately place the good products and defective products in boxes. |
